M5 moldable connector with solder cup pin for wire soldering. This connector is often used for over-mold cable and junction box with IP68 waterproof when mated.
View More
EN / 中文
.jpg "M5 4pins male straight rear panel mount connector, unshielded, solder")
.jpg "M5 4pins male straight rear panel mount connector, unshielded, solder")
.jpg "M5 4pins male straight rear panel mount connector, unshielded, solder")
.jpg "M5 4pins male straight rear panel mount connector, unshielded, solder")
-lp.jpg "Panel Mount Connector - M5 4pins male straight rear panel mount connector, unshielded, solder")
-lp.jpg "Panel Mount Connector - M5 4pins male straight rear panel mount connector, unshielded, solder")
-lp.jpg "Panel Mount Connector - M5 4pins male straight rear panel mount connector, unshielded, solder")
-lp.jpg "Panel Mount Connector - M5 4pins male straight rear panel mount connector, unshielded, solder")
| Part no | 5H006 |
| Brand |
Indus-c |
| MOQ |
100 |
| Place of origin | Shenzhen city, China |
| Delivery time |
3 weeks |
| Standards | IEC 61076-2-105 |
| Termination | Solder |
| Connector locking system | Screw |
| Degree of protection | IP67, IP68, IP69K |
| Wire gauge(mm²) | 0.14mm² |
| Wire gauge(AWG) | 26AWG |
| Mechanical operation | >100 mating cycles |
| Ambient temperature(operation) | -25°C~+85°C |
| Customs tariff number | 8538900000 |
| Environmental compliance | RoHS, Reac |
| 4Pin | 60V |
| Rated voltage | 1A |
| Contact resistance | ≤5mΩ |
| Insulation resistance | ≥100MΩ |
| Connector body | TPU |
| Pin | Brass with gold plated |
| Screw | Brass with nickel plated |
M5 moldable connector with solder cup pin for wire soldering. This connector is often used for over-mold cable and junction box with IP68 waterproof when mated.
View More
M5 moldable connector with solder cup pin for wire soldering. This connector is often used for over-mold cable and junction box with IP68 waterproof when mated.
View More
M5 moldable connector with solder cup pin for wire soldering. This connector is often used for over-mold cable and junction box with IP68 waterproof when mated.
View More
M5 connector series are secure and waterproof with a waterproof IP67, IP68, IP69K rating. A great choice for sensor applications and wet environments, these connectors are gold plated, with 3 and 4 pins, and in cable mount, or panel mount co
View More
