M8 4pins A code male right angle plastic assembly connector, unshielded

M8 connectors for assembly provide the best connection technology for every application where standard cable assemblies with over-molded connectors are not an option. Indus-connector has plastic version both straight type and right angle type optional 3pins and 4pins. What’s more shielded type is also available.
Inquire Online
Download

General information

Part no  8ZU07
Brand

Indus-c

MOQ

100

Place of origin     Shenzhen city, China
Delivery time

3 weeks


General features

Standards IEC 61076-2-104
Termination Screw clamp
Connector locking system Screw
Degree of protection IP67, IP68, IP69K
Wire gauge(mm²) 0.14mm²-0.34mm²
Wire gauge(AWG) 26AWG-22AWG
Suitable cable outer diameter 3.5mm-5.0mm
Mechanical operation >100 mating cycles
Ambient temperature(operation) -25°C~+85°C
Customs tariff number  8538900000
Environmental compliance   RoHS, Reac

Electrical parameters

4Pin 30V
Rated voltage 3A
Contact resistance ≤5mΩ
Insulation resistance ≥100MΩ

Material

Connector body TPU
Pin Brass with gold plated
Screw Brass with nickel plated
Gasket Fluorine ring

NEED MORE INFORMATIONS?

Contact us

mating connectors
