M16 19pins A code male straight to female right angle molded cable,unshielded,PUR,-40°C~+105°C,24AWG 0.25mm²,brass with nickel plated screw

Inquire Online
Download

General information

Part no  16L00399
Brand

Indus-c

MOQ

100

Place of origin     Shenzhen city, China
Delivery time

3 weeks


General features

Standards DIN EN 61076-2-106
Termination Solder and over-mold
Connector locking system Screw
Degree of protection IP67
Wire gauge(mm²) 0.14mm²-0.75mm²
Wire gauge(AWG) 26AWG-18AWG
Mechanical operation >100 mating cycles
Ambient temperature(operation) -25°C~+85°C
Customs tariff number  8538900000
Environmental compliance   RoHS, Reach

Electrical parameters

19Pin 60V
Rated voltage 3.0A
Contact resistance 1010 Ω
Insulation resistance ≥100MΩ

Material

Connector body TPU
Male pin Brass with gold plated
Female pin Phosphorus copper with gold plated
Screw Brass with nickel plated

Download

NEED MORE INFORMATIONS?

Contact us

mating connectors
